Thermostat with sensorModel Name: PCT513-TY-A Power Supply: 24 VAC, 2A Carry; 5A Surge 50/60 Hz Operating Temperature: 32° F to 122° F Humidity range:5%~95% WiFi:802.11 b/g/n @ 2.4GHz Mounting Type: Wall Mounting Dimensions: 160(L) × 87.4(W)× 33(H) mm ![]()
Collect
Basic HVAC Control* Supports 2H/2C multistage conventional system or 4H/2C Heat Pump system * The 4-period and 7-day programming schedule on the device or through the APP * Multiple HOLD options: Permanent Hold, Temporary Hold, Follow Schedule * Automatic heating and cooling changeover * Fan cycle mode periodically circulates fresh air for comfort and health * Smart warmup, low temperature protection
* Support up to 16 remote zone sensors for location-based temperature control * Geofencing * Preheat or precool your house before you get home * Vacation mode * Optional time settings for compressor short cycle protection delay * No click sound when thermostat starts work * Wiring test User Interaction* 4.3” TFT LCD touchscreen * Voice control: Amazon Alexa and Google Home * System status indicated by different backlight colors * Backlight brightness level adjustable * PIR motion detection * Intuitive UI
|
HVAC Control Functions | |
System Mode | Heat, Cool, Auto, Off, Emergency Heat (Heat Pump only) |
Fan Mode | On, Auto, Circulation |
Advanced | Local and remote setting of the temperature |
Auto-changeover between heat and cool mode(System Auto) | |
Compressor short cycle protection delay of 2 minutes | |
Failure protection by cutting off all circuit relays thanks to the Super Capacitor | |
Auto Mode Deadband | 1.5° C, 3° F |
Temp. Sensing Range | −10°C to 125°C |
Temp. Resolution | 0.1° C, 0.2° F |
Temp. Display Accuracy | ±1°C |
Temp. Setpoint Span | 0.5° C, 1° F |
Humidity Sensing Range | 0 to 100% RH |
Humidity Accuracy | ±4% Accuracy through the range of 0% RH to 80% RH |
Humidity Response Time | 18 seconds to reach 63% of the next step value |
Wireless Connectivity | |
ZigBee | ZigBee 2.4GHz IEEE 802.15.4, ZHA1.2 Profile, Router Device |
Output Power | +3dBm (up to +8dBm) |
Receive Sensitivity | -100dBm |
OTA | Optional Over-the-Air Upgradable via wifi |
WiFi | Optional |
Physical Specifications | |
Embedded Platform | MCU: 32-bit Cortex M4; RAM: 192K; SPI Flash: 16M |
LCD Screen | 3.5” TFT Color LCD, 480*320 pixels |
LED | 3-color LED (Red, Blue, Green) |
Buttons | One rotary control wheel, 3 side-buttons |
PIR Sensor | Sensing Distance 5m, Angle 30° |
Speaker | Click sound |
Data Port | Micro USB |
DIP Switch | Power selection |
Electrical Rating | 24 VAC, 2A Carry; 5A Surge 50/60 Hz |
Switches/Relays | Latching type relay, 2A maximum loading |
1. 1st stage control | |
2. 2nd stage control | |
3. 3rd stage control | |
4. Emergency Heating control | |
5. Fan Control | |
6. Heating/cooling Reverse Valve Control | |
7. Common | |
Dimensions | 160(L) × 87.4(W)× 33(H) mm |
Mounting Type | Wall Mounting |
Wiring | 18 AWG, Requires both R and C wires from the HVAC System |
Operating Temperature | 0° C to 40° C (32° F to 104° F) |
Storage Temperature | -30° C to 60° C |
Certification | FCC |
